Model E-188/220
High Frequency, Narrow Beam Ultrasonic Transducer
MassaSonic Model E-188/220 Transducers are uniquely designed to boast a narrow directional pattern completely free of side lobes. Operating at 220 kHz, these transducers feature aluminum housings with a silicon face. These transducers are typically used in non-contact echo ranging applications and are RoHS compliant.
Model TR-2465/150
Narrow Beam Ultrasonic Transducer
Similar to the E-188, the MassaSonic TR-2465 offers narrow directional pattern free of side lobes in an aluminum housing, with a silicone face. Operating at 150kHz, the transducer can function either by transmitting and receiving signals with a single unit or using separate units for each function.
Model TR-89B Series
Cost-Effective Sensitivity & Reliablity
The TR-89B comes in 23 kHz and 40 kHz versions, and can produce high sound pressure levels. This product features a one-piece aluminum housing that is designed to be more environmentally resistant than traditional transducers.
Model TR-2436/150
Plastic Ultrasonic Transducer
The TR-2436 is a 150 kHz transducer that features a plastic housing that can be waterproof when mounted in an appropriate housing.
| MassaSonic Ultrasonic Transducers | |
| Model: | E-188 |
| Frequency: | 220 kHz |
| Range: | Up to 4 ft. |
| Beam Pattern: | Narrow |
| Operating Temp: | -40°C to 85°C |
| Length: | 0.58 inches |
| Diameter: | 0.51 inches |
| Datasheet Links: | E-188/220 |
| MassaSonic Ultrasonic Transducers | |
| Model: | TR-89 |
| Frequency: | 23-40 kHz |
| Range: | Up to 50 ft. |
| Beam Pattern: | Multi-Lobe |
| Operating Temp: | -40°C to 85°C |
| Length: | 0.50 inches |
| Diameter: | 1.0 inches |
| Datasheet Links: | TR-89B |
| MassaSonic Ultrasonic Transducers | |
| Model: | TR-2436 |
| Frequency: | 150 kHz |
| Range: | Up to 8 ft. |
| Beam Pattern: | Medium |
| Operating Temp: | -40°C to 85°C |
| Length: | 0.40 inches |
| Diameter: | 0.72 inches |
| Datasheet Links: | TR-2436/150 |
| MassaSonic Ultrasonic Transducers | |
| Model: | TR-2465 |
| Frequency: | 150 kHz |
| Range: | Up to 12 ft. |
| Beam Pattern: | Narrow |
| Operating Temp: | -40°C to 85°C |
| Length: | 0.50 inches |
| Diameter: | 0.72 inches |
| Datasheet Links: | TR-2465/150 |
